The NXP MC17XS6500BEK is a multifunctional, high-performance system basis chip (SBC) that is designed to cater to the demanding needs of automotive and industrial applications. This advanced IC integrates multiple features to control, monitor, and diagnose loads in various systems.

Key Features

• High Integration: The MC17XS6500BEK combines a voltage regulator, CAN transceiver, and a physical interface for a microcontroller, making it an all-in-one solution for complex control tasks.
• Load Control: It includes four high-side and four low-side MOSFET pre-drivers, providing precise control over a wide range of loads.
• Robust Communication: Equipped with a high-speed CAN interface, the chip ensures reliable communication in networks up to 1 Mbit/s, which is critical for real-time applications.
• Diagnostic Functions: The device comes with extensive diagnostic capabilities, including open load detection, short-circuit monitoring, and over-temperature protection, which help in maintaining system integrity and reliability.
• Power Supply: An integrated voltage regulator supports a 5V or 3.3V supply, which can be used to power external sensors or a microcontroller, simplifying system design.

Applications

The versatility of the MC17XS6500BEK makes it suitable for a wide range of applications, including:

• Automotive systems such as body control modules, gateway modules, and power distribution boxes.
• Industrial control systems that require reliable load switching and monitoring.
• Heavy machinery and agricultural equipment that need robust electronic control units.

Technical Specifications

• Supply voltage range: 6V to 27V
• Operating temperature range: -40°C to 125°C
• Package: 32-lead LQFP

The MC17XS6500BEK is a testament to NXP's commitment to delivering high-quality, integrated solutions that address the complex requirements of modern electronic systems. With its comprehensive feature set and diagnostic capabilities, it stands out as a robust SBC for advanced applications.
