Products specifications

Category Discrete Semiconductor Products
Family Diodes - Rectifiers - Arrays
Manufacturer NXP
Packaging Tube
Diode Configuration 1 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 150V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 1.2V @ 30A
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 28ns
Current - Reverse Leakage @ Vr 100μA @ 150V
Mounting Style Through Hole
Package TO-220-3
Manufacturer Device Package TO-220AB
Win Source Part Number 201724-BYV42E-150
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BYV42E-150 CAD Model

Description

The BYV42E-150 is a robust and efficient dual, ultra-fast, epitaxial rectifier diode, designed and manufactured by NXP Semiconductors, a leader in the electronics industry. This high-performance component is specifically engineered for applications requiring a fast switching diode with low power loss and high efficiency.

Key Features

  • Voltage Rating: The BYV42E-150 is rated for a repetitive peak reverse voltage (V<sub>RRM) of 150V, making it suitable for a wide range of applications in the power management domain.
  • Current Capacity: It has a high average forward current of 30A, which ensures that the device can handle significant levels of current without degradation or failure.
  • Switching Speed: With an ultra-fast reverse recovery time, this diode is optimized for high-frequency switching, reducing losses in converters, inverters, and freewheeling applications.
  • Configuration: The dual diode configuration in a single package allows for space-saving designs and simplifies the layout of power circuits.
  • Thermal Performance: The BYV42E-150 is encapsulated in a SOT78 (TO-220AB) package, which provides excellent thermal conduction and heat dissipation, ensuring the device operates reliably even under high power and temperature conditions.

Applications

The BYV42E-150 is ideal for use in a variety of applications, including:

  • Switch Mode Power Supplies (SMPS)
  • Power Factor Correction circuits
  • Snubber diode for inductive loads
  • Freewheeling diode in converters and motor control circuits
  • High-frequency rectification in power electronics

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality products. The BYV42E-150 is manufactured with the highest standards, ensuring that it meets the rigorous demands of industrial and commercial applications. It provides a reliable solution for designers looking to enhance the efficiency and longevity of their power circuits.

Environmental Compliance

The BYV42E-150 adheres to environmental regulations and is compliant with RoHS standards, minimizing the environmental impact by avoiding the use of hazardous substances.
