Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr NTE
Package Bag
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 50 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 1 V @ 3 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 50 ns
Current - Reverse Leakage @ Vr 10 µA @ 50 V
Capacitance @ Vr, F 45pF @ 4V, 1MHz
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Supplier Device Package DO-201AD
Standard Package 1 pcs
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 694223-UF5400
Ultra Librarian 3D Model Ultra Librarian UF5400 CAD Model

Description

The 694223-UF5400 is a single rectifier diode with a fast recovery time of less than 500 ns.

  • Maximum Voltage Rating: 50 V
  • Average Rectified Current (Io): 3 A
  • Forward Voltage (Vf): 1 V @ 3 A
  • Reverse Recovery Time (trr): 50 ns
  • Reverse Leakage Current: 10 µA @ 50 V
