Same model may have multiple batches, images only for reference.
MABA023500KGS Real Image
Same model may have multiple batches, images only for reference.

MABA023500KGS

Part No MABA023500KGS
Manufacturer Nichicon
Catalog Film Capacitors
Description CAP FILM 0.5UF 10% 600VDC RADIAL / 0.5 µF Film Capacitor 320V 600V Polypropylene (PP), Metallized Radial
Datasheet
MABA023500KGS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Film Capacitors
Mfr Nichicon
Series MAB
Package Bulk
Capacitance 0.5 µF
Tolerance ±10%
Voltage Rating - AC 320V
Voltage Rating - DC 600V
Dielectric Material Polypropylene (PP) , Metallized
Temperature Range - Operating -40°C ~ 100°C
Mounting Type Through Hole
Package / Case Radial
Size / Dimension 1.043" L x 0.335" W (26.50mm x 8.50mm)
Height - Seated (Max) 0.669" (17.00mm)
Termination PC Pins
Lead Spacing 0.886" (22.50mm)
Applications Motor Run
Standard Package 650
MSL Level Not Applicable
ECCN EAR99
HTSUS 8532.25.0070
Win Source Part Number 1341239-MABA023500KGS
Ultra Librarian 3D Model Ultra Librarian MABA023500KGS CAD Model

Description

The Nichicon MAB series film capacitor with a capacitance of 0.5μF and a voltage rating of 320V AC and 600V DC is a high-quality product.

  • Tolerance: ±10%
  • Lead Spacing: 0.886" (22.50mm)
  • Dielectric Material: Polypropylene (PP), Metallized
  • Application: Motor Run
  • Operating Temperature: -40°C ~ 100°C
  • Packaging: Bulk
  • Mounting Type: Through Hole
