PTVS5V0Z1USKNYL Nexperia USA Inc.
Same model may have multiple batches, images only for reference.

PTVS5V0Z1USKNYL

Part No PTVS5V0Z1USKNYL
Manufacturer Nexperia USA Inc.
Catalog TVS - Diodes
Description TVS DIODE 5V 12V DSN1608-2
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Nexperia USA Inc.
Packaging Tape and Reel
Status Obsolete
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff 5V (Maximum)
Voltage - Breakdown (Minimum) 6.4V
Voltage - Clamping (Maximum) at Ipp 12V
Current - Peak Pulse (10/1000μs) 20A
Power - Peak Pulse 200W
Power Line Protection No
Applications General Purpose
Capacitance at Frequency 1200pF at 1MHz
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 0603 (1608 Metric)
Supplier Device Package DSN1608-2
Manufacturer Pack Quantity 10,000
MSL Level 1 (Unlimited)
Win Source Part Number 755758-PTVS5V0Z1USKNYL
Popularity Low
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PTVS5V0Z1USKNYL CAD Model

Description

The Nexperia USA Inc. PTVS5V0Z1USKNYL is a low popularity electronic component that is now obsolete.

  • Manufacturer: Nexperia USA Inc.
  • Popularity: low popularity
  • Status: obsolete
  • Supply and Demand Status: sufficient
  • Manufacturer Pack Quantity: 10,000
  • Type: Zener type
  • Voltage - Reverse Standoff: 5V (Maximum)
  • Voltage - Breakdown (minimum): 6.4V
  • Power - Peak Pulse: 200W
  • Current - Peak Pulse (10/1000μs): 20A
  • Capacitance @ Frequency: 1200pF @ 1MHz
  • Mounting Type: SMD
  • Packaging: tape and reel
  • Manufacturer Package: 0603 (1608 Metric)
  • Supplier Device Package: DSN1608-2
  • Operating Temperature Range: from -40°C to 125°C
