Same model may have multiple batches, images only for reference.

PMLL4148L,115

Name: PMLL4148L,115
Brand: Nexperia USA Inc.
SKU: 506165
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PMLL4148L,115
Manufacturer	Nexperia USA Inc.
Catalog	Diodes, Rectifiers - Single
Description	Small Signal Switching Diodes High-speed switching diodes
Datasheet	PMLL4148L,115 Datasheet
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Nexperia USA Inc.
Packaging	Reel - TR
Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	75V
Current - Average Rectified (Io)	200mA (DC)
Voltage - Forward (Vf) (Max) @ If	1V @ 50mA
Reverse Recovery Time (trr)	4ns
Current - Reverse Leakage @ Vr	25nA @ 20V
Capacitance @ Vr, F	4pF @ 0V, 1MHz
Mounting	SMD (SMT)
Case / Package	SOD-80C
Operating Temperature - Junction	200°C (Max)
Win Source Part Number	1089689-PMLL4148L,115
Popularity	Medium
Supply and Demand Status	Balance
Application Field	Used in Industrial, Power Management, Consumer Electronics, Portable Devices
Ultra Librarian 3D Model	Ultra Librarian PMLL4148L,115 CAD Model

Alternative Products

Description

The Nexperia USA Inc. PMLL4148L,115 is a standard diode with a maximum reverse voltage of 75V and an average rectified current of 200mA (DC).

Manufacturer: Nexperia USA Inc.
Diode Type: Standard
Maximum Reverse Voltage: 75V
Average Rectified Current: 200mA (DC)
Maximum Forward Voltage: 1V @ 50mA
Reverse Recovery Time: 4ns
Reverse Leakage Current: 25nA @ 20V
Capacitance: 4pF @ 0V, 1MHz
Package: SOD-80C
Operating Temperature: Up to 200°C
