PMEG6030EP,115 Nexperia USA Inc. PMEG6030EP,115 real image PMEG6030EP,115 real image 2
Same model may have multiple batches, images only for reference.
PMEG6030EP,115 Nexperia USA Inc. PMEG6030EP,115 real image PMEG6030EP,115 real image 2
PMEG6030EP,115 Nexperia USA Inc. PMEG6030EP,115 real image PMEG6030EP,115 real image 2
Same model may have multiple batches, images only for reference.

PMEG6030EP,115

Part No PMEG6030EP,115
Manufacturer Nexperia USA Inc.
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 60V 3A SOD128 / Rectifier Diode Schottky 60V 3A Automotive 2-Pin SOD-128 T/R
Datasheet
PMEG6030EP,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 60V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 530mV @ 3A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 200μA @ 60V
Capacitance @ Vr, F 360pF @ 1V, 1MHz
Mounting SMD (SMT)
Case / Package CFP5
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 1089651-PMEG6030EP,115
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name PMEG6030EP
Introduction Date October 20, 2009
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian PMEG6030EP,115 CAD Model

Description

The PMEG6030EP,115 is a Schottky diode with a maximum DC reverse voltage of 60V and an average rectified current of 3A.

  • Maximum DC Reverse Voltage: 60V
  • Average Rectified Current: 3A
  • Forward Voltage: 530mV @ 3A
  • Reverse Leakage Current: 200μA @ 60V
  • Capacitance: 360pF @ 1V, 1MHz
  • Mounting Technology: SMD (SMT)
  • Package: CFP5
  • Speed/Frequency: Fast recovery @ 200mA (Io)
