PMEG45U10EPDZ

Name: PMEG45U10EPDZ
Brand: Nexperia USA Inc.
SKU: 1085675
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	PMEG45U10EPDZ
Manufacturer	Nexperia USA Inc.
Catalog	Diodes, Rectifiers - Single
Description	DIODE SCHOTTKY 45V 10A CFP15 / Diode Schottky 45 V 10A Surface Mount CFP15
Datasheet	PMEG45U10EPDZ Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Diodes - Rectifiers - Single
Mfr	Nexperia USA Inc.
Package	Tape & Reel
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	45 V
Current - Average Rectified (Io)	10A
Voltage - Forward (Vf) (Max) @ If	490 mV @ 10 A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)	34 ns
Current - Reverse Leakage @ Vr	600 µA @ 45 V
Capacitance @ Vr, F	1170pF @ 1V, 1MHz
Mounting	SMD (SMT)
Package / Case	TO-277, 3-PowerDFN
Supplier Device Package	CFP15
Operating Temperature - Junction	150°C (Max)
Base Product Number	PMEG45U10
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Other Names	1727-1833-2,PMEG45U10EPDZ-ND,1727-1833-1,568-11469-6,568-11469-6-ND,568-11469-2-ND,568-11469-1-ND,934068206146,568-11469-1,1727-1833-6,568-11469-2
Standard Package	1,500
Win Source Part Number	1085675-PMEG45U10EPDZ
Ultra Librarian 3D Model	Ultra Librarian PMEG45U10EPDZ CAD Model

Alternative Products

Description

The PMEG45U10EPDZ is a Schottky Diode that comes with a Fast Recovery speed of less than 500ns and greater than 200mA (Io).

DC Reverse Voltage (Vr): 45V
Average Rectified Current (Io): 10A
Voltage Forward (Vf): 490mV @ 10A
Reverse Recovery Time (trr): 34ns
Current Reverse Leakage @ Vr: 600µA @ 45V
Capacitance @ Vr, F: 1170pF @ 1V, 1MHz
Maximum Junction Temperature: 150°C
Package: TO-277, 3-PowerDFN
Supplier Device Package: CFP15
Alternative Part: SB2003M-TL-W, SS14HE, SS16HE, SS13HE, SS2003M-TL-E, and SBE808-TL-W934068206146
