The PESD36VS2UT is a low-capacitance bidirectional Electrostatic Discharge (ESD) protection diode manufactured by Nexperia. It's designed to protect sensitive electronic components from damage caused by ESD events. It offers a high level of protection while maintaining signal integrity in high-speed data lines.

Applications

• USB interfaces
• HDMI interfaces
• Antenna ports
• Ethernet interfaces
• Mobile devices

Features

• Bidirectional ESD protection
• Low clamping voltage
• Ultra-low capacitance
• Fast response time
• Small footprint package

Benefits

• Protects sensitive components from ESD damage
• Maintains signal integrity in high-speed applications
• Reduces system downtime and repair costs
• Easy to implement in circuit designs
• Enhances product reliability

Additional Details

The PESD36VS2UT has a very low capacitance, which minimizes signal distortion in high-speed data transmission. Its low clamping voltage ensures that the voltage seen by the protected component during an ESD event is kept to a safe level. The device meets industry standards for ESD protection, such as IEC 61000-4-2. Refer to the datasheet for detailed specifications including breakdown voltage, capacitance, and clamping voltage characteristics. The small footprint package is ideal for space-constrained applications.
