Same model may have multiple batches, images only for reference.
BZT52H-C6V8,115 Nexperia USA Inc.
Same model may have multiple batches, images only for reference.

BZT52H-C6V8,115

Part No BZT52H-C6V8,115
Manufacturer Nexperia USA Inc.
Catalog Diodes - Zener - Single
Description DIODE ZENER 6.8V 375MW SOD123F
Datasheet
BZT52H-C6V8,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Voltage - Zener (Nom) (Vz) 6.8V
Tolerance ±5%
Maximum Power Dissipation 375mW
Impedance (Max) (Zzt) 8 Ohm
Current - Reverse Leakage @ Vr 2μA @ 4V
Voltage - Forward (Vf) (Max) @ If 900mV @ 10mA
Temperature Range - Operating -65°C to 150°C
Mounting SMD (SMT)
Case / Package SOD-123F
Win Source Part Number 1026074-BZT52H-C6V8,115
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian BZT52H-C6V8,115 CAD Model

Description

The Nexperia USA Inc. BZT52H-C6V8,115 is a zener diode that is designed for use in a variety of electronic applications.

  • Voltage - Zener (Nom) (Vz): 6.8V
  • Impedance (Max) (Zzt): 8 Ohm
  • Voltage - Forward (Vf) (Max) @ If: 900mV @ 10mA
  • Current - Reverse Leakage @ Vr: 2μA @ 4V
  • Status: Active
  • Supply and Demand: Sufficient
  • Popularity: Medium
  • Case/Package: SOD-123F
  • Maximum Power Dissipation: 375mW
