Part No BAV99S,115
Manufacturer Nexperia USA Inc.
Catalog Diodes, Rectifiers - Arrays
Description Small Signal Switching Diodes High-speed switching diode
Datasheet
BAV99S,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Nexperia USA Inc.
Series Automotive, AEC-Q101, BAV99
Package Tape & Reel
Product Status Active
Diode Configuration 2 Pair Series Connection
Technology Standard
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) (per Diode) 200mA (DC)
Voltage - Forward (Vf) (Max) @ If 1.25 V @ 150 mA
Speed Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr) 4 ns
Current - Reverse Leakage @ Vr 500 nA @ 80 V
Operating Temperature - Junction 150°C (Max)
Mounting Type Surface Mount
Package / Case 6-TSSOP, SC-88, SOT-363
Supplier Device Package 6-TSSOP
Base Product Number BAV99
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 843170-BAV99S,115
Ultra Librarian 3D Model Ultra Librarian BAV99S,115 CAD Model

Description

The BAV99S,115 is a diode array from Nexperia USA Inc.

  • Series: BAV99
  • Application: Automotive
  • Maximum DC Reverse Voltage: 100V
  • Maximum Forward Voltage: 1.25V @ 150mA
  • Speed: Small Signal
  • Reverse Recovery Time: 4ns
  • Package: 6-TSSOP, Surface Mount
  • Current Rating: 200mA per Diode
  • Maximum Operating Temperature: 150°C
