BAS40-07,215 Nexperia USA Inc. BAS40-07,215 real image BAS40-07,215 label picture
Same model may have multiple batches, images only for reference.
BAS40-07,215 Nexperia USA Inc. BAS40-07,215 real image BAS40-07,215 label picture
BAS40-07,215 Nexperia USA Inc. BAS40-07,215 real image BAS40-07,215 label picture
Same model may have multiple batches, images only for reference.

BAS40-07,215

Part No BAS40-07,215
Manufacturer Nexperia USA Inc.
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 40V SOT143B
Datasheet
BAS40-07,215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Diode Configuration 2 Independent
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) (per Diode) 120mA (DC)
Voltage - Forward (Vf) (Max) @ If 1V @ 40mA
Current - Reverse Leakage @ Vr 10μA @ 40V
Operating Temperature - Junction 150°C (Max)
Mounting SMD (SMT)
Case / Package SOT-143B
Win Source Part Number 1022087-BAS40-07,215
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian BAS40-07,215 CAD Model

Description

The Nexperia USA Inc. BAS40-07,215 is a Schottky diode designed for discrete semiconductor products.

  • Voltage - DC Reverse (Vr) (Max): 40V
  • Voltage - Forward (Vf) (Max) @ If: 1V @ 40mA
  • Current - Reverse Leakage @ Vr: 10μA @ 40V
  • Diode Configuration: 2 independent
  • Operating Temperature - Junction: 150°C (Max)
  • Current - Average Rectified (Io) (per diode): 120mA (DC)
  • Package: SMD (SMT)
  • Case: SOT-143B
