1PS76SB21,115

Name: 1PS76SB21,115
Brand: Nexperia USA Inc.
SKU: 416782
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	1PS76SB21,115
Manufacturer	Nexperia USA Inc.
Catalog	Diodes, Rectifiers - Single
Description	Rectifier Diode Schottky 40V 0.2A Automotive 2-Pin SOD-323 T/R / DIODE SCHOTTKY 40V 200MA SOD323
Datasheet	1PS76SB21,115 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Nexperia USA Inc.
Packaging	Reel - TR
Status	Active
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	40V
Current - Average Rectified (Io)	200mA (DC)
Voltage - Forward (Vf) (Max) @ If	550mV @ 200mA
Current - Reverse Leakage @ Vr	15μA @ 30V
Capacitance @ Vr, F	50pF @ 0V, 1MHz
Mounting	SMD (SMT)
Case / Package	SOD-323
Operating Temperature - Junction	125°C (Max)
Win Source Part Number	1002481-1PS76SB21,115
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	1PS76SB21
Introduction Date	July 16, 1998
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2026
Ultra Librarian 3D Model	Ultra Librarian 1PS76SB21,115 CAD Model

Alternative Products

Description

The Nexperia USA Inc. 1PS76SB21 Schottky diode is a high-performance diode with a maximum reverse voltage of 40V and an average rectified current of 200mA (DC).

Forward Voltage: 550mV @ 200mA
Reverse Leakage Current: 15μA @ 30V
Capacitance: 50pF @ 0V and 1MHz
