NX5032GA-8.000M-STD-CSU-1 Real Image NX5032GA-8.000M-STD-CSU-1 Real Image
Same model may have multiple batches, images only for reference.
NX5032GA-8.000M-STD-CSU-1 Real Image NX5032GA-8.000M-STD-CSU-1 Real Image
NX5032GA-8.000M-STD-CSU-1 Real Image NX5032GA-8.000M-STD-CSU-1 Real Image
Same model may have multiple batches, images only for reference.

NX5032GA-8.000M-STD-CSU-1

Part No NX5032GA-8.000M-STD-CSU-1
Manufacturer NDK
Catalog Oscillators
Description CRYSTAL 8.0000MHZ 8PF SMD
Datasheet
NX5032GA-8.000M-STD-CSU-1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators - Crystals
Mfr NDK
Series NX5032GA
Package Tape & Reel
Product Status Active
Type MHz Crystal
Frequency 8 MHz
Frequency Stability ±150ppm
Frequency Tolerance ±50ppm
Load Capacitance 8pF
ESR (Equivalent Series Resistance) 300 Ohms
Operating Mode Fundamental
Temperature Range - Operating -40°C ~ 150°C
Ratings AEC-Q200
Mounting Type Surface Mount
Package / Case 2-SMD, No Lead
Size / Dimension 0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Max) 0.059" (1.50mm)
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.60.0050
Win Source Part Number 929549-NX5032GA-8.000M-STD-CSU-1
Ultra Librarian 3D Model Ultra Librarian NX5032GA-8.000M-STD-CSU-1 CAD Model

Description

The NX5032GA series is a MHz crystal with a frequency of 8 MHz.

  • Frequency: 8 MHz
  • Mounting: Surface Mount
  • Size: 0.197" L x 0.126" W (5.00mm x 3.20mm)
  • Height: 0.059" (1.50mm)
  • Frequency Stability: ±150ppm
  • Frequency Tolerance: ±50ppm
  • Mode: Fundamental
  • Load Capacitance: 8pF
  • Packaging: Tape & Reel
  • Package Type: 2-SMD, no lead
  • Temperature Range: -40°C to 150°C
  • Application: Automotive (AEC-Q200)
  • Manufacturer: NDK
  • Status: Active
