Same model may have multiple batches, images only for reference.
75757-1101 Real Image
Same model may have multiple batches, images only for reference.

75757-1101

Part No 75757-1101
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Unshrouded Header HDR 20 POS 3.5mm Solder ST Thru-Hole MX 150™ Automotive Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Brass
Contact Plating Tin
Country of Origin TW
Current Rating 16 A
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Material Thermoplastic
Max Operating Temperature 125 °C
Min Operating Temperature -40 °C
Number of Circuits 20
Number of Positions 20
Number of Rows 2
Orientation Vertical
Pitch 3.5 mm
Plating Tin
REACH SVHC No SVHC
RoHS Compliant
Termination Through Hole
Voltage Rating (DC) 500 V
Win Source Part Number 1216142-75757-1101
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 75757-1101 CAD Model

Description

The Molex 1216142-75757-1101 is a vertical connector that is through-hole terminated.

  • Positions: 20
  • Number of Rows: 2
  • Current Rating: 16 A
  • Contact Material: brass
  • Contact Plating: tin
  • Housing Material: thermoplastic
  • Color: black
  • RoHS Compliant: Yes
