67800-8005 Real Image
Same model may have multiple batches, images only for reference.

67800-8005

Part No 67800-8005
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description PCB Header; 2.54 mm; 10 Way 1 Row RightAngle; AMPMODU System 50 Series
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type SATA
Contact Material Brass
Contact Plating Gold
Country of Origin US
Current Rating 1.5 A
Depth 6.45 mm
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Height 8.65 mm
Housing Material Thermoplastic
Lead Free Yes
Lead Pitch 1.27 mm
Length 16.9 mm
Maximum Operating Temperature 85 °C
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 7
Number of Contacts 7
Number of Ports 1
Number of Positions 7
Number of Rows 1
Number of Terminals 7
Orientation Vertical
Pitch 1.27 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 15 V
Win Source Part Number 975656-67800-8005
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 67800-8005 CAD Model

Description

The Molex 975656-67800-8005 is a 7-position vertical SATA connector with a pitch of 1.27 mm.

  • Voltage Rating: 15 V
  • Current Rating: 1.5 A
  • Material: Brass with gold plating
  • RoHS Compliant: Yes
  • Minimum Operating Temperature: -55 °C
  • Maximum Operating Temperature: 85 °C
  • Lead-Free: Yes
  • Mounting: Through hole
