54722-0504 Real Image
Same model may have multiple batches, images only for reference.

54722-0504

Part No 54722-0504
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Board to Board & Mezzanine Connectors .6FHP04H, 050, S, STD 08/SN, ST, NSYES
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Bronze
Contact Plating Gold
Country of Origin JP
Current Rating 500 mA
ELV Compliant
Gender Receptacle
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Material Thermoplastic
Lead Pitch 500 µm
Material Bronze
Mount Surface Mount
Number of Circuits 50
Number of Contacts 50
Number of Positions 50
Number of Rows 2
Orientation Vertical
Pitch 500 µm
Plating Gold
REACH SVHC No SVHC
RoHS Compliant
Row Spacing 1.5 mm
Termination SMD/SMT
Voltage Rating 50 V
Win Source Part Number 987868-54722-0504
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 54722-0504 CAD Model

Description

The 987868-54722-0504 is a 50-position vertical receptacle connector with a pitch of 500μm and a row spacing of 1.5mm.

  • Positions: 50
  • Orientation: Vertical
  • Pitch: 500μm
  • Row Spacing: 1.5mm
  • Current Rating: 500mA
  • Voltage: 50V
  • Contact Material: Bronze
  • Contact Plating: Gold
  • Housing Material: Thermoplastic
  • Termination: Surface Mount (SMD/SMT)
  • RoHS: Compliant
  • Halogen: Low Halogen
  • Package: TSSOP16
  • Category: Circular Connectors - Housings
  • Popularity: Low
  • Supply: Short
