53254-0770 Real Image
Same model may have multiple batches, images only for reference.

53254-0770

Part No 53254-0770
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header HDR 7 POS 2mm Solder RA Thru-Hole Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Gender Male
Contact Material Brass
Contact Plating Tin
Country of Origin MY
Current Rating 2 A
Gender Male
Glow Wire Compliant Non-compliant
Housing Material Nylon
Maximum Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 7
Number of Contacts 7
Number of Positions 7
Number of Rows 1
Orientation Right Angle
Pitch 2 mm
Plating Tin
REACH SVHC Unknown
RoHS Compliant
Termination Through Hole
Voltage Rating 125 V
Win Source Part Number 1039196-53254-0770
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 53254-0770 CAD Model

Description

The Molex 1039196-53254-0770 is a through-hole circular connector housing with 7 positions and 1 row.

  • Positions: 7
  • Rows: 1
  • Pitch: 2mm
  • Gender: Male
  • Housing Material: Nylon
  • Contact Material: Brass
  • Contact Plating: Tin
  • Voltage Rating: 125V
  • Current Rating: 2A
  • RoHS Compliant: Yes
  • Minimum Operating Temperature: -40°C
  • Maximum Operating Temperature: 105°C
