53254-0670

Part No 53254-0670
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn IDC Connector HDR 6 POS 2mm Solder RA Thru-Hole Box/Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Contact Gender Male
Contact Material Brass
Contact Plating Tin
Country of Origin MY
Current Rating 2 A
Flammability Rating UL94 V-0
Glow Wire Compliant Non-compliant
Housing Material Nylon
Lead Pitch 2 mm
Maximum Operating Temperature 105 °C
Max Voltage Rating (AC) 125 V
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 6
Number of Contacts 6
Number of Positions 6
Number of Rows 1
Orientation Right Angle
Pitch 2 mm
Plating Tin
REACH SVHC Unknown
RoHS Compliant
Termination Through Hole
Voltage Rating 125 V
Voltage Rating (DC) 125 V
Win Source Part Number 1029792-53254-0670
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 53254-0670 CAD Model

Description

The 53254-0670 is a housing for a Picoflex PF-50 Connector from Molex. This housing is designed to securely hold the connector terminals and provide a robust connection in various wire-to-board applications using ribbon cable. The Picoflex PF-50 series is known for its reliable performance in signal and power applications.

Applications

  • Signal and Power Applications
  • Robotics
  • Automotive
  • Consumer Electronics
  • Test and Measurement Equipment

Features

  • Number of Circuits: 6
  • Pitch: 1.27mm
  • Locking Style: Positive Lock
  • Material: Typically Nylon or similar high-performance plastic
  • Color: Natural (often white or beige)
  • Housing Type: Receptacle

Benefits

  • Provides a secure and reliable connection.
  • Positive lock prevents accidental disconnection.
  • Durable material ensures long-lasting performance.
  • Easy to assemble with compatible Picoflex PF-50 terminals.
  • Suited for applications requiring ribbon cable connections.

Additional Details

The 53254-0670 housing is designed to mate with corresponding Picoflex PF-50 headers on a printed circuit board. The 1.27mm pitch allows for a high density of connections in a small area and allows to be used with standard ribbon cables. The positive locking mechanism provides an audible click when the connector is fully mated, ensuring a secure connection. The housing is typically made of a high-performance plastic material that is resistant to heat, chemicals, and vibration. This connector system is suitable for a wide range of applications where a reliable ribbon cable connector is required. The operating temperature range is typically -40°C to +105°C depending on the specific material used. The housing is designed to accept crimp terminals that are attached to a ribbon cable, simplifying assembly. The terminals are then securely retained within the housing by internal locking features.
