46114-8200

Part No 46114-8200
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn LPH RCP 28 POS 1.27mm Solder ST Thru-Hole 28 Terminal 1 Port Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Receptacle
Contact Material Brass, Tin
Contact Plating Gold
Country of Origin CN
Depth 8.33 mm
Flammability Rating UL94 V-0
Housing Material Polymer
Maximum Operating Temperature 105 °C
Max Voltage Rating (AC) 250 V
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 28
Number of Ports 1
Number of Positions 28
Number of Rows 2
Number of Terminals 52
Orientation Vertical
Plating Tin
Radiation Hardening No
RoHS Compliant
Termination Press-Fit
Voltage Rating 250 V
Win Source Part Number 1038750-46114-8200
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 46114-8200 CAD Model

Description

The 46114-8200 Receptacle Connector is a high-quality electronic component manufactured by Molex, LLC.

  • Positions: 28
  • Color: Black
  • Rows: 2
  • Termination: Press-Fit
  • Contact Material: Brass
  • Contact Plating: Tin
  • Contact Plating: Gold
  • Housing Material: Polymer
  • Flammability Rating: UL94 V-0
  • Voltage Rating: 250 V
  • Maximum Operating Temperature: 105°C
  • Depth: 8.33 mm
  • Mounting: Through Hole
  • RoHS: Compliant
  • Radiation Hardening: Yes
