43045-0816 Real Image
Same model may have multiple batches, images only for reference.

43045-0816

Part No 43045-0816
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Micro-Fit Power HDR 8 POS 3mm Solder ST SMD 8 Terminal 1 Port Emboss T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Brass
Contact Plating Gold
Contact Resistance 10 mΩ
Country of Origin US
Current Rating 5 A
Depth 8.77 mm
Fastening Type Ramp
Housing Color Black
Housing Material Polymer
Lead Pitch 3 mm
Length 16.15 mm
Max Operating Temperature 105 °C
Max Voltage Rating (AC) 250 V
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 8
Number of Contacts 8
Number of Positions 8
Number of Rows 2
Orientation Vertical
Pitch 3 mm
Plating Tin
RoHS Compliant
Row Spacing 2.9972 mm
Termination Solder
Voltage Rating (DC) 250 V
Win Source Part Number 1202824-43045-0816
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 43045-0816 CAD Model

Description

The 1202824-43045-0816 circular connector housing is a male pin connector from Molex, LLC.

  • Positions: 8
  • Pitch: 3 mm
  • Color: Black
  • Rows: 2
  • Row Spacing: 2.9972 mm
  • Termination: Soldered
  • Fastening Type: Ramp
  • Contact Material: Brass
  • Current Rating: 5 A
  • Length: 16.15 mm
  • Housing Material: Polymer
  • Orientation: Vertical
  • Contact Plating: Gold
  • Housing Color: Black
  • Contact Resistance: 10 mΩ
  • RoHS Compliant: Yes
