The 35363-0560 is a Micro-Fit 3.0 Connector Header manufactured by Molex, LLC. This connector header is designed for wire-to-board connections in various electronic applications. Its compact size and high current carrying capacity make it suitable for space-constrained and power-intensive applications.

Applications

• Power Supplies: Used for connecting power sources to circuit boards.
• Industrial Equipment: Employed in industrial control systems and machinery.
• Consumer Electronics: Found in appliances, gaming consoles, and other consumer devices.
• Automotive Electronics: Utilized in automotive control units and wiring harnesses.
• Telecommunications Equipment: Used for connecting various modules in telecommunications systems.

Features

• Micro-Fit 3.0 Series: Compact size with a 3.0mm pitch.
• 5 Circuits: Provides connectivity for five individual circuits.
• Through-Hole Termination: Designed for through-hole mounting on PCBs.
• High Current Capacity: Supports high current flow for power applications.
• Polarization Features: Prevents mismating and ensures correct connection.

Benefits

• Space Saving: Compact design allows for high-density board layouts.
• Reliable Connection: Provides a secure and reliable electrical connection.
• Easy Installation: Through-hole termination simplifies the soldering process.
• Versatile Application: Suitable for a wide range of electronic applications.
• Error Prevention: Polarization features prevent incorrect mating.

Additional Details

The Micro-Fit 3.0 connector series is known for its compact size and robust design. The 35363-0560 header is typically used with mating connectors from the Micro-Fit 3.0 series to create a complete wire-to-board connection. The header is made from durable materials to withstand harsh environmental conditions and ensure long-term reliability.

Molex, LLC is a leading global manufacturer of electronic connectors and interconnect solutions. Their products are widely used in various industries, including automotive, telecommunications, and consumer electronics.

When selecting connectors like the 35363-0560, it's important to consider factors such as the number of circuits, current rating, voltage rating, and operating temperature. These parameters should be compatible with the application requirements to ensure proper functionality and safety. Molex provides detailed datasheets for their connectors, including specifications, dimensions, and performance characteristics.
