15916044

Get a Quote

Part No	15916044
Manufacturer	Molex, LLC
Catalog	Rectangular Connectors
Description	CGRID SMT HDR TIN 4CKT
Datasheet	15916044 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Connectors, Interconnects
Manufacturer	Molex, LLC
Series	C-Grid 71308
Packaging	Reel package
Connector Type	Header, Breakaway
Contact Type	Male Pin
Pitch - Mating	0.100" (2.54mm)
Style	Board to Board or Cable
Shrouding	Unshrouded
Number of Positions	4
Number of Positions Loaded	All
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting	SMD
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.240" (6.10mm)
Insulation Height	0.050" (1.27mm)
Contact Shape	Square
Contact Finish - Mating	Tin
Contact Finish Thickness - Mating	150μin (3.81μm)
Contact Finish - Post	Tin
Contact Material	Copper Alloy
Insulation Material	Liquid Crystal Polymer (LCP), Glass Filled
Features	Board Guide, Pick and Place
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Contact Finish Thickness - Post	150μin (3.81μm)
Applications	Automotive, General Purpose, Lighting, Medical, Telecommunications
Win Source Part Number	763663-15916044
Popularity	Medium
Supply and Demand Status	Limited
Family Name	71308
Introduction Date	March 30, 2010
ECCN	EAR99
Country of Origin	Mexico, United States of America, United States of America
Halogen Free	Compliant
Estimated EOL Date	2028
Ultra Librarian 3D Model	Ultra Librarian 15916044 CAD Model

Description

The Molex, LLC C-Grid 71308 header connector is a 4-position, board-to-board or cable connector with a pitch of 0.100" (2.54mm).

Positions: 4
Connector Type: Board-to-Board or Cable
Pitch: 0.100" (2.54mm)
Contact Type: Male Pin
Mounting: Surface Mount
Fastening Type: Push-Pull
Contact Material: Copper Alloy
Flammability Rating: UL94 V-0
Applications: Automotive, General-Purpose, Lighting, Medical, Telecommunications
Insulation Material: Liquid Crystal Polymer (LCP), Glass-Filled
Shrouding: Unshrouded
Contact Finish: 150μin (3.81μm) (Mating and Post)
Insulation Height: 0.050" (1.27mm)
RoHS Compliant: Yes
Halogen Free: Yes
ECCN: EAR99
