15-91-0260 Real Image
Same model may have multiple batches, images only for reference.

15-91-0260

Part No 15-91-0260
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Unshrouded Header HDR 26 POS 2.54mm Solder ST Top Entry SMD C-Grid® Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Bronze
Contact Mating Length 6.096 mm
Contact Plating Gold
Contact Resistance 15 mΩ
Country of Origin US
Current Rating 3 A
Depth 5.08 mm
Housing Color Black
Housing Material Polymer
Lead Pitch 2.54 mm
Length 33.02 mm
Maximum Operating Temperature 105 °C
Max Voltage Rating (AC) 250 V
Max Voltage Rating (DC) 250 V
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 24
Number of Contacts 26
Number of Positions 26
Number of Rows 2
Orientation Vertical
Pitch 2.54 mm
Plating Tin
RoHS Compliant
Row Spacing 2.54 mm
Termination Solder
Voltage Rating (DC) 250 V
Win Source Part Number 1034844-15-91-0260
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 15-91-0260 CAD Model

Description

Molex, LLC 1034844-15-91-0260 is a 26-contact male pin connector with a 2.54 mm pitch. Molex, LLC 1034844-15-91-0260 is a 26-contact male pin connector with a 2.54 mm pitch.

  • Contacts: 26
  • Gender: male pin
  • Pitch: 2.54 mm
  • Current Rating: 3 A
  • Contact Resistance: 15 mΩ
  • Length: 33.02 mm
  • Housing Material: polymer
  • Termination: solder
  • Contact Plating: gold
  • RoHS Compliant: Yes
  • Maximum Operating Temperature: 105 °C
  • Mounting: surface mount
  • Supply: shortage
