Same model may have multiple batches, images only for reference.
09-48-1114 Real Image
Same model may have multiple batches, images only for reference.

09-48-1114

Part No 09-48-1114
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description KK 396 PC Board Connector, Right Angle, Polyester Connector, 5.00µm Tin (Sn), 11 Circuits
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color White
Connector Type Receptacle, Socket
Contact Material Bronze
Contact Plating Tin
Contact Resistance 6 mΩ
Country of Origin PR
Current Rating 5 A
Fastening Type Ramp
Gender Female
Housing Color White
Housing Material Polyester
Lead Free Yes
Maximum Operating Temperature 75 °C
Min Operating Temperature 0 °C
Mount Through Hole
Number of Circuits 10
Number of Contacts 11
Number of Positions 11
Number of Rows 1
Orientation Right Angle
Packaging Bulk
Pitch 3.96 mm
Plating Tin
RoHS Compliant
Termination Solder
Voltage Rating 250 V
Win Source Part Number 1041113-09-48-1114
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 09-48-1114 CAD Model

Description

The Molex 1041113-09-48-1114 is a 1-row, 11-position receptacle, socket connector with a pitch of 3.96 mm.

  • Voltage Rating: 250 V
  • Current Rating: 5 A
  • Housing Material: polyester
  • Contact Material: bronze
  • Contact Plating: tin
  • Housing Color: white
  • Contact Resistance: 6 mΩ
  • Compliance: RoHS compliant
  • Mounting Style: through-hole
  • Usage: suitable for use in circular connectors - housings
