Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category RF and Wireless - RF Amplifiers
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Frequency 50MHz ~ 4GHz
P1dB 23.2dBm
Gain 18dB
Noise Figure 1.5dB
RF Type CATV, Cellular, DBS, MMDS, PCS, WLAN, Wireless LAN
Voltage - Supply 4.8V ~ 3V, 5.2V
Current - Supply 97mA
Test Frequency 4GHz
Mounting Type Surface Mount
Package / Case TO-243AA
Supplier Device Package SOT-89
Base Product Number PGA-103
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.33.0001
Win Source Part Number 273596-PGA-103+
Ultra Librarian 3D Model Ultra Librarian PGA-103+ CAD Model

Description

The Mini-Circuits 273596-PGA-103+ is an RF amplifier manufactured by Mini-Circuits and is suitable for various applications.

  • Frequency Range: 50MHz to 4GHz
  • Gain: 18dB
  • Noise Figure: 1.5dB
  • Current Supply: 97mA
  • Voltage Supply: 4.8V to 3V and 5.2V
  • Mounting: Surface Mount
  • Package: TO-243AA
  • Supplier Device Package: SOT-89
  • Status: Active
