Same model may have multiple batches, images only for reference.

JANTXV1N5772

Name: JANTXV1N5772
Brand: Microsemi Corporation
SKU: 608864
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	JANTXV1N5772
Manufacturer	Microsemi Corporation
Catalog	TVS - Diodes
Description	Isolated Diode Array with HiRel MQ, MX, MV, and MSP Screening Options
Datasheet	JANTXV1N5772 Datasheet
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Circuit Protection
Manufacturer	Microsemi Corporation
Series	Military, MIL-PRF-19500/474
Packaging	Tube
Type	Steering (Rail to Rail)
Unidirectional Channels	8
Power Line Protection	No
Applications	Ethernet
Operating Temperature Range	-65°C ~ 150°C (TJ)
Mounting	SMD
Package	10-CFlatPack
Manufacturer Package	10-CFlatpack
RoHS State	Request Verification
Win Source Part Number	1191552-JANTXV1N5772
Manufacturer Homepage	www.microsemi.com
Popularity	Medium
Supply and Demand Status	Limited
Family Name	1N5772
Introduction Date	June 18, 1997
ECCN	EAR99
Quantity per package	1
Ultra Librarian 3D Model	Ultra Librarian JANTXV1N5772 CAD Model

Alternative Products

Description

The Microsemi Corporation 1N5772 is a Military, MIL-PRF-19500/474 series, steering (rail to rail) type electronic component.

Package: 10-CFlatPack
Mounting: Surface mountable
Ideal for: Ethernet applications
Channels: 8 unidirectional
Current-Peak Pulse: 10/1000μs
Power Line Protection: No
Operating Temperature: -65°C ~ 150°C (TJ)
Function: Circuit protection
