1N5824

Name: 1N5824
Brand: Microsemi Corporation
SKU: 416630
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	1N5824
Manufacturer	Microsemi Corporation
Catalog	Diodes, Rectifiers - Single
Description	DIODE SCHOTTKY 5A 30V TOPHAT
Datasheet	1N5824 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Microsemi Corporation
Packaging	Bulk
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	30V
Current - Average Rectified (Io)	5A
Voltage - Forward (Vf) (Max) @ If	370mV @ 5A
Speed(Frequency)	Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr	10mA @ 30V
Mounting	Through Hole
Case / Package	Axial
Operating Temperature - Junction	-65°C to 125°C
Win Source Part Number	1002329-1N5824
Popularity	Medium
Supply and Demand Status	Limited
Quantity per package	1
Ultra Librarian 3D Model	Ultra Librarian 1N5824 CAD Model

Alternative Products

Description

The Microsemi Corporation 1N5824 is a Schottky diode that comes in an axial package.

Voltage Rating: 30V
Average Rectified Current: 5A
Forward Voltage: 370mV @ 5A
Reverse Leakage Current: 10mA @ 30V
Operating Temperature Range: -65°C to 125°C
Recovery Speed: 200mA (Io)
Package: Bulk
