Product Overview: PIC24F32KA304-I/PT

The PIC24F32KA304-I/PT is a high-performance, 16-bit microcontroller from the renowned manufacturer Microchip Technology. This microcontroller is part of the PIC24F family, which is well-known for its low power consumption and versatility, making it an ideal choice for a wide range of embedded applications.

Key Features

• Core: 16-bit PIC24F CPU
• Max Speed: 32 MHz
• Program Memory: 32 KB of Flash
• RAM: 4 KB
• Data EEPROM: 1 KB
• Timers: Multiple 16-bit and 32-bit timers
• I/O Pins: Up to 24 with multiple mappable functions
• Communication Interfaces: I²C, SPI, UART
• Analog Features: 10-bit ADC with up to 13 channels, comparators
• Temperature Range: -40°C to 85°C
• Package: 44-pin TQFP

Advanced Peripherals and Integration

The PIC24F32KA304-I/PT microcontroller includes advanced peripherals such as Charge Time Measurement Unit (CTMU) for capacitive touch applications, a Real-Time Clock/Calendar (RTCC), and Power-on Reset (POR), Brown-out Reset (BOR), and Watchdog Timer (WDT) for reliable operation. The device also supports Direct Memory Access (DMA) for efficient data transfers without CPU intervention.

Power Management

With its various power-saving modes, including Idle and Sleep modes, the PIC24F32KA304-I/PT excels in applications where power efficiency is crucial. It also features an on-chip voltage regulator and an ultra-low-power wake-up for further power optimization.

Applications

This microcontroller is ideal for applications in the industrial, automotive, and consumer sectors. Common uses include sensor interfacing, automotive control systems, home automation, portable devices, and IoT applications, where a combination of performance, low power, and a rich set of peripherals is essential.
