Microchip Technology MCP6282T-E/SN Operational Amplifier

The MCP6282T-E/SN is a high-performance operational amplifier (op-amp) designed and manufactured by Microchip Technology, a leading provider of microcontroller, mixed-signal, analog, and Flash-IP solutions. This op-amp is part of the MCP6282 family, which is known for its low-power consumption and rail-to-rail input/output operation, making it a versatile choice for a wide range of applications.

Key Features

• Low Power Consumption: The MCP6282T-E/SN is optimized for low-power applications, requiring just 210 µA per amplifier, which is ideal for battery-powered devices and power-sensitive applications.
• Rail-to-Rail Input/Output: This feature allows for a wider dynamic range, making the most of the supply voltage range. It is particularly useful in single-supply operations and low-voltage applications.
• Gain Bandwidth Product: With a gain bandwidth product of 2 MHz, this op-amp can handle a broad range of frequencies, suitable for various signal processing tasks.
• Extended Temperature Range: The MCP6282T-E/SN operates over an industrial temperature range from -40°C to +125°C, ensuring reliability and performance under extreme conditions.
• Supply Voltage: It operates from a single supply voltage ranging from 2.4V to 5.5V, making it compatible with most low-voltage systems and standard logic levels.

Applications

The MCP6282T-E/SN is a versatile component that can be used in a variety of electronic circuits and systems. Some common applications include:

• Portable Instrumentation
• Test and Measurement Systems
• Sensor Interfaces
• Consumer Electronics
• Active Filter Blocks
• Medical Devices
• Analog-to-Digital Converter Driver

Package and Quality

The device comes in an 8-pin SOIC (Small Outline Integrated Circuit) package, which is widely used and easy to integrate into various circuit designs. The MCP6282T-E/SN also adheres to Microchip's commitment to high-quality standards, ensuring both robustness and longevity for the end-user's application.

With its combination of features, the MCP6282T-E/SN operational amplifier from Microchip Technology is an excellent choice for designers looking for a low-power, high-precision component for their electronic designs.
