SMBJ15CA-TP Real Image SMBJ15CA-TP real image11064 SMBJ15CA-TP Real Image
Same model may have multiple batches, images only for reference.
SMBJ15CA-TP Real Image SMBJ15CA-TP real image11064 SMBJ15CA-TP Real Image
SMBJ15CA-TP Real Image SMBJ15CA-TP real image11064 SMBJ15CA-TP Real Image
Same model may have multiple batches, images only for reference.

SMBJ15CA-TP

Part No SMBJ15CA-TP
Manufacturer Micro Commercial Co
Catalog TVS - Diodes
Description TVS DIODE 15VWM 24.4VC SMB
Datasheet
SMBJ15CA-TP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Micro Commercial Co
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 15V
Minimum Breakdown Voltage 16.7V
Max Clamping Voltage 24.4V
Peak Pulse Current(Ippm) 24A
Power Dissipation - Pd 600W
Applications General Purpose
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package DO-214AA (SMB)
Win Source Part Number 1097736-SMBJ15CA-TP
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian SMBJ15CA-TP CAD Model

Description

The Micro Commercial Co SMBJ15CA-TP is a zener diode with a stand-off voltage of 15V and a minimum breakdown voltage of 16.7V.

  • Stand-Off Voltage: 15V
  • Minimum Breakdown Voltage: 16.7V
  • Maximum Clamping Voltage: 24.4V
  • Peak Pulse Current: 24A
  • Power Dissipation: 600W
  • Operating Temperature Range: -55°C to 175°C
  • Package: DO-214AA (SMB)
