Products specifications

Standard Package 20
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1299900-SMDJ40C
Other Names 2997-SMDJ40CTR
Package / Case DO-214AB (SMC)
Mounting SMD (SMT)
Temperature Range - Operating -55°C ~ 150°C
Applications General Purpose
Power - Peak Pulse 3000W (3kW)
Current - Peak Pulse (10/1000µs) 42.02A
Voltage - Clamping (Max) @ Ipp 71.4V
Voltage - Breakdown (Min) 44.4V
Voltage - Reverse Standoff (Typ) 40V
Bidirectional Channels 1
Type Zener
Package Tape & Reel (TR)
Series SMDJ
Mfr Meritek
Category Circuit Protection>TVS - Diodes
Ultra Librarian 3D Model Ultra Librarian SMDJ40C CAD Model

Description

The Meritek SMDJ40C is a unidirectional zener TVS diode designed for general-purpose circuit protection.

  • Package: DO-214AB (SMC)
  • Mounting Technique: SMD (SMT)
  • Reverse Standoff Voltage: 40V
  • Breakdown Voltage: 44.4V
  • Clamping Voltage: 71.4V @ a peak pulse power of 3kW
  • Operating Temperature Range: -55°C to 150°C
  • Application: Ideal for power line protection
