MMC3280MS Memsic Inc.
Same model may have multiple batches, images only for reference.

MMC3280MS

Part No MMC3280MS
Manufacturer Memsic Inc.
Catalog Magnetic Sensors - Linear, Compass (ICs)
Description MAGNETIC SENSOR 3-AXIS
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Magnetic Sensors - Linear, Compass (ICs)
Mfr Memsic Inc.
Package Tape & Reel
Product Status Obsolete
Technology Magnetoresistive
Axis X, Y, Z
Output Type I2C
Sensing Range ±0.8mT
Voltage - Supply 1.62V ~ 3.6V
Current - Supply (Max) 800µA
Resolution 14 b
Bandwidth 25Hz
Temperature Range - Operating -40°C ~ 85°C
Features Temperature Compensated
Supplier Device Package 10-LGA (3.05x3.05)
Mounting Type Surface Mount
Package / Case 10-TFLGA Exposed Pad
Standard Package 3,000 pcs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN OBSOLETE
Win Source Part Number 235867-MMC3280MS
Ultra Librarian 3D Model Ultra Librarian MMC3280MS CAD Model

Description

The MMC3280MS is a magnetic sensor designed for linear and compass applications.

  • Package: 10-TFLGA exposed pad
  • Mounting: surface mountable
  • Series: MMC3280
  • Manufacturer: Memsic Inc.
  • Feature: Temperature compensated
  • Output: I2C
  • Bandwidth: 25Hz
  • Voltage Supply Range: 1.62V to 3.6V
  • Current Supply: 800µA
  • Sensing Range: ±0.8mT
  • Resolution: 14 bits
  • REACH compliant: Yes
  • ECCN: OBSOLETE
  • Recommendation: Not Recommended for New Designs
