PLP-45-48 Mean Well Enterprises Co., Ltd.
Same model may have multiple batches, images only for reference.

PLP-45-48

Part No PLP-45-48
Manufacturer Mean Well Enterprises Co., Ltd.
Catalog External/Internal (Off - Board) LED Drivers
Description LED DRVR CC AC/DC 36-48V 950MA
Datasheet
PLP-45-48 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - External/Internal (Off-Board) - LED Drivers
Mfr Mean Well Enterprises Co., Ltd.
Series PLP-45 (45W)
Package Box
Product Status Not For New Designs
Programmable Not Verified
Type Constant Current
Topology AC DC Converter
Number of Outputs 1
Voltage - Input (Min) 90VAC
Voltage - Input (Max) 264VAC
Voltage - Output 36 ~ 48V
Current - Output (Max) 950mA
Power (Watts) 46 W
Voltage - Isolation 3.75 kV
Features OCP, OVP, SCP
Temperature Range - Operating -30°C ~ 70°C
Efficiency 89%
Termination Style Rectangular, 2 Position
Size / Dimension 4.00" L x 2.00" W x 1.17" H (101.6mm x 50.8mm x 29.6mm)
Approval Agency CB, CCC, CE, TUV, UR
Mounting Type Chassis Mount
Base Product Number PLP-45
Standard Package 96 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9510
Win Source Part Number 656028-PLP-45-48
Ultra Librarian 3D Model Ultra Librarian PLP-45-48 CAD Model

Description

The Mean Well PLP-45-48 is a 46W constant current LED driver.

  • Termination Style: Rectangular, 2 position
  • Protection Features: Over current protection (OCP), over voltage protection (OVP), and short circuit protection (SCP)
  • Package Quantity: 96 pieces in a box
  • Dimensions: 4.00" L x 2.00" W x 1.17" H (101.6mm x 50.8mm x 29.6mm)
  • Suitable for: AC-DC converter applications
  • Power Output: 46W
  • Efficiency: 89%
  • Voltage Output: 36 ~ 48V
  • Voltage Isolation: 3.75 kV
  • Maximum Output Current: 950mA
  • Input Voltage: 90VAC to 264VAC
