PLC-100-48 Mean Well Enterprises Co., Ltd.
Same model may have multiple batches, images only for reference.

PLC-100-48

Part No PLC-100-48
Manufacturer Mean Well Enterprises Co., Ltd.
Catalog External/Internal (Off - Board) LED Drivers
Description LED DRIVER CC/CV AC/DC 48V 2A
Datasheet
PLC-100-48 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - External/Internal (Off-Board) - LED Drivers
Mfr Mean Well Enterprises Co., Ltd.
Series PLC-100 (100W)
Package Box
Product Status Active
Programmable Not Verified
Type Constant Current, Voltage
Topology AC DC Converter
Number of Outputs 1
Voltage - Input (Min) 90VAC
Voltage - Input (Max) 264VAC
Voltage - Output 48V
Current - Output (Max) 2A
Power (Watts) 96 W
Voltage - Isolation 3.75 kV
Features OTP, OVP, SCP
Temperature Range - Operating -30°C ~ 50°C
Efficiency 88.5%
Termination Style Wire Leads
Size / Dimension 7.89" L x 2.74" W x 1.38" H (200.5mm x 69.5mm x 35.0mm)
Approval Agency CB, CCC, CE, PSE, TUV, UR
Mounting Type Chassis Mount
Base Product Number PLC-100
Standard Package 25 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9520
Win Source Part Number 655974-PLC-100-48
Ultra Librarian 3D Model Ultra Librarian PLC-100-48 CAD Model

Description

The PLC-100-48 is a 100W constant current/voltage LED driver from Mean Well Enterprises Co., Ltd. It is designed for power supplies in external/internal (off-board) LED driver applications.

  • Voltage Output: 48V
  • Termination Style: wire leads
  • Protection: overtemperature protection (OTP), overvoltage protection (OVP), and short circuit protection (SCP)
  • Size: 7.89" L x 2.74" W x 1.38" H
  • Efficiency: 88.5%
  • Temperature Range: -30°C to 50°C
  • Approvals: CB, CCC, CE, PSE, TUV, and UR
