ELP-75-24-C Real Image
Same model may have multiple batches, images only for reference.

ELP-75-24-C

Part No ELP-75-24-C
Manufacturer Mean Well Enterprises Co., Ltd.
Catalog Board Mount AC DC Converters
Description AC/DC CONVERTER 24V 76W / Enclosed AC DC Converters 1 Output 24V 90 ~ 264 VAC, 127 ~ 370 VDC Input
Datasheet
ELP-75-24-C Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - External/Internal (Off-Board)>AC DC Converters
Mfr MEAN WELL USA Inc.
Series ELP-75 (75W)
Package Box
Product Status Obsolete
Type Enclosed
Number of Outputs 1
Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
Voltage - Output 1 24V
Current - Output 1 3.15 A
Power (Watts) 76W
Applications ITE (Commercial)
Voltage - Isolation 3 kV
Efficiency 90%
Temperature Range - Operating -30°C ~ 70°C (With Derating)
Features Adjustable Output, Universal Input
Mounting Type Chassis Mount
Dimension 7.68" L x 2.68" W x 1.30" H (195.0mm x 68.0mm x 33.0mm)
Approval Agency CB, CE, cURus, TUV
Minimum Load Required No
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9520
Other Names ELP-75-24-C-ND,1866-1601
Standard Package 25
Win Source Part Number 1057108-ELP-75-24-C
Ultra Librarian 3D Model Ultra Librarian ELP-75-24-C CAD Model

Description

The ELP-75-24-C is a 75W enclosed AC/DC converter from MEAN WELL USA Inc. ELP-75-24-C is manufactured by MEAN WELL USA Inc.

  • Power: 75W
  • Type: Enclosed AC/DC Converter
  • Output: Adjustable
  • Input: Universal Input
  • Application: ITE (Commercial)
  • Standard Package: 25
  • Power Rating: 76W
  • Input Voltage: 90 ~ 264 VAC, 127 ~ 370 VDC
  • Isolation Voltage: 3 kV
  • Output Voltage: 24V
  • Efficiency: 90%
  • Minimum Load: None
  • Mounting: Chassis
  • Operating Temperature: -30°C to 70°C (With Derating)
  • Dimension: 7.68" L x 2.68" W x 1.30" H (195.0mm x 68.0mm x 33.0mm)
  • Status: Obsolete
  • Approvals: CB, CE, cURus, TUV
