ESD5Z5V0 ESD5Z5V0 Real Image
Same model may have multiple batches, images only for reference.
ESD5Z5V0 ESD5Z5V0 Real Image
ESD5Z5V0 ESD5Z5V0 Real Image
Same model may have multiple batches, images only for reference.

ESD5Z5V0

Part No ESD5Z5V0
Manufacturer MDD
Catalog TVS - Diodes
Description TVS DIODE 5VWM 11.6VC SOD523
Datasheet
ESD5Z5V0 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr MDD
Series SOD-523
Package Tape & Reel
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 5V
Voltage - Breakdown (Min) 6.2V
Current - Peak Pulse (10/1000µs) 5A (8/20µs)
Power - Peak Pulse 174W
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 80pF @ 1MHz
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case SOD-523
Supplier Device Package SOD-523
Standard Package 12,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 918697-ESD5Z5V0
Ultra Librarian 3D Model Ultra Librarian ESD5Z5V0 CAD Model

Description

The 918697-ESD5Z5V0 is a Zener type transient voltage suppressor (TVS) diode designed for general-purpose applications.

  • Type: Zener TVS Diode
  • Application: General Purpose
  • Package: Surface Mount (SOD-523)
  • Packaging: Tape and Reel
  • Standard Package: 12,000 pieces
  • Reverse Standoff Voltage: 5V
  • Breakdown Voltage: 6.2V
  • Peak Pulse Power: 174W
  • Power Line Protection: Yes
  • Capacitance: 80pF @ 1MHz
  • Peak Pulse Current: 5A (10/1000µs)
  • Operating Temperature: -55°C to 150°C
  • Status: Active
  • REACH: Unaffected
  • Manufacturer: MDD
