Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 5/3
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 28-SSOP
Win Source Part Number 021533-MAX3238EAI+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX3238EAI+ CAD Model

Description

Maxim Integrated's MAX3238EAI+: High-Performance 3V to 5.5V, Up to 1Mbps, RS-232 Transceivers

The MAX3238EAI+ is a sophisticated serial communication component designed by Maxim Integrated to facilitate RS-232 communication in applications requiring data rates up to 1Mbps. This integrated circuit is capable of operating with a supply voltage range from 3V to 5.5V, making it versatile for use in various systems including portable or battery-powered devices.

With its integrated electrostatic discharge (ESD) protection, the MAX3238EAI+ ensures reliability and durability, safeguarding against the common issue of ESD damage that can occur during handling and operation. The device is capable of withstanding ESD events up to ±15kV using the Human Body Model, providing a robust solution for industrial environments and consumer products alike.

The MAX3238EAI+ features an automatic shutdown function that conserves power when not in use, making it an energy-efficient choice for power-sensitive applications. This power-saving feature is particularly useful in battery-operated devices, where extending battery life is critical.

This RS-232 transceiver includes five drivers and three receivers, offering a complete serial port suitable for modem interface applications. Its flexibility is further enhanced by its compatibility with the V.28 and RS-232 standards, ensuring it can be integrated into a wide range of communication systems without compatibility issues.

The MAX3238EAI+ comes in a 28-pin SSOP package, which is designed to occupy minimal space on a printed circuit board. This compact footprint allows for more efficient use of board space, which is especially valuable in space-constrained applications such as handheld devices.

Overall, the MAX3238EAI+ from Maxim Integrated is an exceptional choice for designers looking for a high-speed, low-power RS-232 interface solution that does not compromise on performance or reliability. Whether used in industrial automation, point-of-sale systems, or mobile communications, this transceiver is engineered to deliver consistent, high-quality communication.
