Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 100mV
Data Rate 10Mbps
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 021419-MAX3086EESD+T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MAX3086E
Introduction Date September 01, 2000
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian MAX3086EESD+T CAD Model

Description

Maxim Integrated MAX3086EESD+T RS-485/RS-422 Transceiver

The MAX3086EESD+T is a robust RS-485/RS-422 transceiver module from Maxim Integrated, designed to facilitate bidirectional data communication on balanced multipoint bus transmission lines. This transceiver is optimized for high-speed operation, capable of transmitting data at rates of up to 10Mbps, making it an excellent choice for industrial, networking, and telecommunications applications where reliable and fast data transfer is a must.

Encased in a space-saving SOIC-8 package, the MAX3086EESD+T is equipped with a variety of features that enhance its performance and reliability in challenging environments. It boasts a wide common-mode voltage range, which makes it tolerant to ground potential differences, ensuring signal integrity across various systems. Additionally, the device includes fail-safe circuitry that guarantees a logic-high receiver output when the receiver inputs are open or shorted, or when they are connected to a terminated transmission line with all drivers disabled.

With an extended ESD protection of ±15kV using the Human Body Model, the MAX3086EESD+T ensures resilience against electrostatic discharges, making it suitable for use in environments where ESD events are a common concern. Its half-duplex configuration allows for two-way communication over a single pair of wires, further simplifying network design and reducing cabling costs.

Among its other notable features, the MAX3086EESD+T includes thermal shutdown protection to prevent damage from overheating, and a low quiescent current that makes it ideal for power-sensitive applications. The device operates over a wide temperature range of -40°C to +85°C, ensuring reliable performance under extreme temperature conditions. Its integrated hot-swap capability allows for live insertion and removal of nodes without causing glitches on the data bus.

Whether it's for factory automation, HVAC systems, or data acquisition units, the MAX3086EESD+T is a versatile and durable solution that offers high-speed data transmission with robust protection features. It is a testament to Maxim Integrated's commitment to providing high-quality and reliable communication solutions for a wide array of electronic applications.
