Maxim Integrated MAX3074EASA+ RS-485/RS-422 Transceiver

The MAX3074EASA+ is a high-performance, half-duplex transceiver from Maxim Integrated, designed for RS-485 and RS-422 communication interfaces. This device is crafted to deliver reliable data transmission over long distances and in electrically noisy environments, making it an ideal choice for industrial, network, and telecommunication applications.

Key Features

• Data Rate: Supports data rates up to 250kbps, ensuring efficient communication for a variety of system requirements.
• Extended Temperature Range: Operates over a wide temperature range from -40°C to +85°C, suitable for harsh industrial environments.
• Robust ESD Protection: Equipped with ±15kV Human Body Model (HBM) electrostatic discharge protection on the transceiver's input and output pins, safeguarding the device against electrical stress.
• Fail-Safe Receiver: Features a fail-safe receiver that guarantees a logic-high receiver output when the receiver inputs are open or shorted, or when they are connected to a terminated transmission line with all drivers disabled.
• Low Power Shutdown: Includes a low-power shutdown mode that reduces current consumption when the transceiver is not in use.
• Pin Compatibility: The MAX3074EASA+ is pin-compatible with the industry-standard MAX1487 and offers an upgraded solution with enhanced specifications.

Applications

The MAX3074EASA+ is versatile and can be used in a variety of applications including, but not limited to:

• Industrial Control Systems
• Building Automation
• Network Equipment
• Telecommunication Systems

Package and Quality

Housed in a compact 8-pin NSOIC package, the MAX3074EASA+ is designed for space-constrained applications. Maxim Integrated is committed to maintaining the highest quality and reliability standards, ensuring that this transceiver meets the stringent requirements of industrial-grade components.
