Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tray
Status Active
Type Transceiver
Protocol T1/E1/J1
Number of Drivers/Receivers 8/8
Duplex Full
Supply Voltage - Operating 3.135 V to 3.465 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 256-CSBGA (17x17)
Win Source Part Number 014763-DS26518GN+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DS26518GN+ CAD Model

Description

The DS26518GN+ is a versatile multi-protocol transceiver from Maxim Integrated, designed to handle various interface standards with a single chip solution. This highly integrated device is ideal for applications requiring connection to different types of telecom equipment, simplifying design and reducing time to market.

Key Features

  • Multi-Protocol Support: The transceiver supports a wide range of protocols including T1, E1, J1, and more, making it a flexible choice for telecommunications projects.
  • Integrated Jitter Attenuator: The onboard jitter attenuator ensures signal integrity by reducing the effects of clock and data recovery jitter.
  • High Port Density: The DS26518GN+ offers high port density, allowing for the design of compact systems with multiple communication interfaces.
  • Low Power Consumption: Designed with power efficiency in mind, the transceiver operates with low power consumption, which is critical for high-density systems and power-sensitive applications.
  • Robust Feature Set: The device includes features such as loss of signal detection, programmable loopbacks, and error monitoring, which contribute to its reliability and ease of maintenance.

Applications

The DS26518GN+ is suitable for a variety of applications, including but not limited to:

  • Telecommunications switching systems
  • Channel banks and multiplexers
  • Wireless base station controllers
  • Central office switches
  • Network interface units

Technical Specifications

The device comes in a compact 64-pin LQFP package and operates over a temperature range of -40°C to +85°C. It features a single 3.3V power supply, which simplifies power management in system design. The DS26518GN+ also meets the stringent requirements of international interface standards, ensuring compatibility and interoperability with a wide range of telecom equipment.

Ordering Information

The DS26518GN+ is available for order, and detailed datasheets, application notes, and additional resources can be found on Maxim Integrated's official website or through authorized distributors. Designers and engineers can rely on Maxim's support and resources to integrate the DS26518GN+ into their next-generation communication solutions.
