SML-LX1210IIC-TR

Part No SML-LX1210IIC-TR
Manufacturer Lumex Opto/Components Inc.
Catalog LED Indication - Discrete
Description LED RED CLEAR 1210 SMD / Red LED Indication - Discrete 2V 1210 (3225 Metric)
Datasheet
SML-LX1210IIC-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics>LED Indication - Discrete
Mfr Lumex Opto/Components Inc.
Package Tape & Reel (TR)
Product Status Obsolete
Color Red
Configuration Standard
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 10mcd
Lens Style Rectangle with Flat Top
Lens Size 2.00mm x 2.70mm
Voltage - Forward (Vf) (Typ) 2V
Current - Test 20mA
Viewing Angle 160°
Mounting SMD (SMT)
Wavelength - Peak 635nm
Package / Case 1210 (3225 Metric)
Supplier Device Package 1210
Dimension 3.20mm L x 2.70mm W
Height (Max) 1.10mm
Base Product Number SML-LX1210
Other Names SMLLX1210IICTR,67-1704-6R,67-1704-2,67-1704-1,67-1704-2R,67-1704-1R,67-1704-6
Standard Package 3,000
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 1241714-SML-LX1210IIC-TR
Ultra Librarian 3D Model Ultra Librarian SML-LX1210IIC-TR CAD Model

Description

This LED component is an SMD (SMT) mounting style with a tape and reel (TR) package.

  • Color: Red
  • Viewing Angle: 160 degrees
  • Millicandela Rating: 10mcd
  • Voltage-Forward (Vf) (Typ): 2V
  • Lens Color: Colorless
  • Lens Transparency: Clear
  • Wavelength-Peak: 635nm
  • Height (max): 1.10mm
  • Package/Case: 1210 (3225 metric)
  • Supplier Device Package: 1210
  • Lens Style: Rectangle with a flat top
  • Lens Size: 2.00mm x 2.70mm
  • Status: Obsolete
