SP36-01WTG-C-HV

Part No SP36-01WTG-C-HV
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 36VWM 48VC 2FLIPCHIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 36V (Max)
Voltage - Breakdown (Min) 40V
Voltage - Clamping (Max) @ Ipp 48V
Current - Peak Pulse (10/1000µs) 1.5A (8/20µs)
Power - Peak Pulse 100W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 10pF @ 1MHz
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Case / Package 2-XFDFN, FCDFN
Supplier Device Package 2-FlipChip
Package Tape & Reel
Supply and Demand Status Limited
Win Source Part Number 1492624-SP36-01WTG-C-HV
Ultra Librarian 3D Model Ultra Librarian SP36-01WTG-C-HV CAD Model
