SMAJ5.0A Real Image SMAJ5.0A label picture SMAJ5.0A real image SMAJ5.0A real image5576 SMAJ5.0A real image5577
Same model may have multiple batches, images only for reference.
SMAJ5.0A Real Image SMAJ5.0A label picture SMAJ5.0A real image SMAJ5.0A real image5576 SMAJ5.0A real image5577
SMAJ5.0A Real Image SMAJ5.0A label picture SMAJ5.0A real image SMAJ5.0A real image5576 SMAJ5.0A real image5577
Same model may have multiple batches, images only for reference.

SMAJ5.0A

Part No SMAJ5.0A
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 5VWM 9.2VC SMA
Datasheet
SMAJ5.0A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6.4V
Max Clamping Voltage 9.2V
Peak Pulse Current(Ippm) 43.5A
Power Dissipation - Pd 400W
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package DO-214AC (SMA)
Win Source Part Number 029063-SMAJ5.0A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Series *
Package Tape & Reel (TR)
Product Status Active
Grade -
Ultra Librarian 3D Model Ultra Librarian SMAJ5.0A CAD Model

Description

The Littelfuse Inc. 029063-SMAJ5.0A is a high popularity electronic component that is used for circuit protection.

  • Type: Zener Diode
  • Maximum Clamping Voltage: 9.2V
  • Peak Pulse Current: 43.5A
  • Mounting: Surface-mount device
  • Applications: General purpose voltage regulation and protection against transient voltage spikes
  • Packaging: Tape and reel
  • Alternative Parts: SMAJ5.0A-E3/61, P4SMAJ5.0A-TP, and TFMAJ5.0A
