P6SMB400A Real Image P6SMB400A real image
Same model may have multiple batches, images only for reference.
P6SMB400A Real Image P6SMB400A real image
P6SMB400A Real Image P6SMB400A real image
Same model may have multiple batches, images only for reference.

P6SMB400A

Part No P6SMB400A
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS Diode Single Uni-Dir 342V 600W 2-Pin SMB T/R / TVS DIODE 342VWM 548VC SMD
Datasheet
P6SMB400A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection
Family TVS - Diodes
Manufacturer Littelfuse Inc.
Series P6SMB
Packaging Reel(TR)
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 342V
Voltage - Breakdown (Min) 380V
Voltage - Clamping (Max) @ Ipp 548V
Current - Peak Pulse (10/1000μs) 1.1A
Power - Peak Pulse 600W
Power Line Protection No
Applications General Purpose
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package DO-214AA, SMB
Manufacturer Device Package DO-214AA (SMBJ)
Win Source Part Number 026344-P6SMB400A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Industrial
Family Name P6SMB400A
Introduction Date October 01, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian P6SMB400A CAD Model

Description

The Littelfuse Inc. P6SMB400A is a TVS diode manufactured by Littelfuse Inc. This zener type diode is packaged in a DO-214AA, SMB package and has an operating temperature range of -55 to 150 degrees Celsius.

  • Package: DO-214AA, SMB
  • Operating Temperature Range: -55 to 150 degrees Celsius
  • Voltage Reverse Standoff: 342V
  • Breakdown Voltage: 380V
  • Peak Pulse Current: 1.1A
  • Maximum Clamping Voltage: 548V
  • Power Peak Pulse: 600W
  • Application: General-purpose
