3KP15A Real Image1 3KP15A Real Image2
Same model may have multiple batches, images only for reference.
3KP15A Real Image1 3KP15A Real Image2
3KP15A Real Image1 3KP15A Real Image2
Same model may have multiple batches, images only for reference.

3KP15A

Part No 3KP15A
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 15VWM 24.4VC P600 / 24.4V Clamp 123A Ipp Tvs Diode Through Hole P600
Datasheet
3KP15A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Transient Voltage Suppressors (TVS)>TVS Diodes
Mfr Littelfuse Inc.
Series 3KP
Package Tape & Reel
Product Status Obsolete
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 15V
Voltage - Breakdown (Min) 16.7V
Voltage - Clamping (Max) @ Ipp 24.4V
Current - Peak Pulse (10/1000µs) 123A
Power - Peak Pulse 3000W (3kW)
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency -
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case P600, Axial
Supplier Device Package P600
Base Product Number 3KP
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Standard Package 800 pcs
Win Source Part Number 1380799-3KP15A
Ultra Librarian 3D Model Ultra Librarian 3KP15A CAD Model

Description

The 1197936 is a TVS diode from the 3KP series.

  • Type: Zener, Unidirectional
  • Voltage - Reverse Standoff (Typ): 15V
  • Voltage - Breakdown (Min): 16.7V
  • Voltage - Clamping (Max) @ Ipp: 24.4V
  • Power - Peak Pulse: 3000W (3kW)
  • Application: General Purpose
  • Mounting Type: Through Hole
  • Packaging: Tape & Reel
  • HTSUS Code: 8541.10.0080
  • Manufacturer: Littelfuse Inc.
  • Lifecycle Status: Obsolete
