Same model may have multiple batches, images only for reference.
2920L250DR Real Image
Same model may have multiple batches, images only for reference.

2920L250DR

Part No 2920L250DR
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description PTC RESETTABLE 15V 2.5A SMD 2920
Datasheet
2920L250DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Polymeric
Voltage - Max 15V
Current - Max 40A
Current - Hold (Ih) (Max) 2.5A
Current - Trip (It) 5A
Time to Trip 10s
Resistance - Initial (Ri) (Min) 35 mOhm
Resistance - Post Trip (R1) (Max) 85 mOhm
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Dimension 0.289" L x 0.202" W (7.35mm x 5.12mm)
Thickness (Max) 0.049" (1.25mm)
Approvals cURus, TUV
Win Source Part Number 1003671-2920L250DR
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 2920L250DR CAD Model

Description

The Littelfuse Inc. 1003671-2920L250DR is a polymeric type circuit protection device.

  • Approvals: cURus and TUV
  • Mounting: SMD (SMT) technology
  • Maximum Voltage Rating: 15V
  • Maximum Current Rating: 40A
  • Current-Hold (Ih) Rating: 2.5A
  • Current-Trip (It) Rating: 5A
  • Time-to-Trip: 10s
  • Thickness: 0.049" (1.25mm)
  • Operating Temperature Range: -40°C to 85°C
  • Resistance - Initial (Ri) Rating: 35 mOhm
  • Resistance - Post Trip (R1) Rating: 85 mOhm
  • Dimension: 0.289" L x 0.202" W (7.35mm x 5.12mm)
  • Popularity: popular in the market
