Part No 0505016.MXP
Manufacturer Littelfuse Inc.
Catalog Fuses
Description FUSE CERAMIC 16A 500VAC/VDC 3AB / Axial Lead & Cartridge Fuses 3AB > Fast-Acting > 505 Series
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Littelfuse Inc.
Packaging Bulk
Fuse Type Cartridge, Ceramic
Current Rating (Amps) 16A
Voltage Rating - AC 500V
Voltage Rating - DC 500V
Response Time Fast Blow
Manufacturer Package 3AB, 3AG, 1/4" x 1-1/4"
Mounting Style Holder
Breaking Capacity at Rated Voltage 50kA AC, 20kA DC
Melting I2t 51
Approvals CE, cULus
Temperature Range - Operating -55°C ~ 125°C
Dimension 0.250" Dia x 1.250" L (6.35mm x 31.75mm)
DC Cold Resistance 0.0073 Ohms
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 809568-0505016.MXP
Ultra Librarian 3D Model Ultra Librarian 0505016.MXP CAD Model

Description

The Littelfuse Inc. 809568-0505016. The manufacturer is Littelfuse Inc.

  • Part Number: Win Source
  • Type: Fast Blow Fuse
  • Current Rating: 16A
  • Breaking Capacity @ Rated Voltage: 50kA AC and 20kA DC
  • DC Cold Resistance: 0.0073 Ohms
  • Response Time: Fast
  • Approvals: CE, cULus
  • MSL Level: 1 (Unlimited)
  • Package: 3AB, 3AG, 1/4" x 1-1/4"
  • Pack Quantity: 1,000
  • Temperature Range: -55°C to 125°C
  • Dimension: 0.250" Dia x 1.250" L (6.35mm x 31.75mm)
  • Supply and Demand Status: Limited
