0259.500T Littelfuse Inc.
Same model may have multiple batches, images only for reference.

0259.500T

Part No 0259.500T
Manufacturer Littelfuse Inc.
Catalog Electrical, Specialty Fuses
Description FUSE BRD MNT 500MA 125VAC/VDC / 500mA 125 V AC 125 V DC Fuse Board Mount Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Electrical, Specialty Fuses
Mfr Littelfuse Inc.
Series 259
Package Bulk
Product Status Active
Mounting Type Through Hole
Fuse Type Board Mount
Current Rating (Amps) 500mA
Voltage Rating - AC 125 V
Voltage Rating - DC 125 V
Response Time Fast Blow
Applications Hazardous Locations
Features Intrinsically Safe
Class -
Approval Agency Baseefa, UR
Temperature Range - Operating -55°C ~ 90°C
Breaking Capacity @ Rated Voltage 50A AC, 300A DC
Package / Case Radial, Can, Horizontal
Size / Dimension 0.315" Dia x 0.512" L (8.00mm x 13.00mm)
Melting I²t 0.0598
DC Cold Resistance 0.302 Ohms
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.10.0040
Win Source Part Number 1361436-0259.500T
Ultra Librarian 3D Model Ultra Librarian 0259.500T CAD Model

Description

The 259-500T is an intrinsically safe electrical specialty fuse from Littelfuse Inc.

  • Temperature Range: -55°C to 90°C
  • Suitable for: Hazardous Locations
  • Current Rating: 500mA
  • Voltage Rating: 125V AC/DC
  • Mounting Type: Board Mount
  • Package: Radial, Can, Horizontal
  • Response Time: Fast Blow
  • Breaking Capacity (AC): 50A AC @ Rated Voltage
  • Breaking Capacity (DC): 300A DC @ Rated Voltage
  • DC Cold Resistance: 0.302 Ohms
  • Approvals: Baseefa and UR
