The LCMX02-640HC-4TG100I is a Field Programmable Gate Array (FPGA) from Lattice Semiconductor, part of the MachXO2 family. This device is designed for low-power and instant-on operation, making it a good choice for a variety of applications where power consumption is a key concern. The 'TG100I' designation indicates that it's packaged in a 100-pin TQFP (Thin Quad Flat Pack) package and specified for the industrial temperature range.

Applications

• Industrial Control Systems
• Embedded Systems
• Automotive Applications
• Communication Equipment
• Medical Devices

Features

• 640 Look-Up Tables (LUTs)
• 32 kbits Embedded Block RAM
• sysMEM Embedded Memory
• sysIO High-Performance I/O
• Up to 200 MHz Internal Clock Frequency
• On-Chip Oscillator
• Instant-On Operation
• Low Power Consumption
• IEEE 1149.1 Boundary Scan Support
• 100-pin TQFP package

Benefits

• Flexibility: The programmable nature allows designers to implement custom logic and adapt to changing requirements without requiring hardware modifications.
• Low Power: Suitable for battery-powered applications and energy-conscious designs.
• Cost-Effective: Provides a cost-optimized solution compared to custom ASICs for moderate complexity logic designs.
• Fast Time-to-Market: Enables rapid prototyping and development due to the ease of reprogramming.
• Integration: Integrates multiple logic functions into a single chip, reducing board space and complexity.

Technical Specifications

The LCMX02-640HC-4TG100I operates on a 1.2V power supply and is designed for operation within the industrial temperature range. It supports various I/O standards. Refer to the Lattice Semiconductor MachXO2 datasheet for detailed electrical characteristics, timing specifications, and package dimensions.
